Solatek AC Output Sine Wave Filter 93KW 3P

Manufacturer: Solatek

SKU: INV-S-PUM-SWF-93

Call for pricing

Overview
Download

FEATURES

Solatek AC Output Sine Wave Filter is designed for PWM inverter outputs to reduce high-frequency components, motor noise, electromagnetic interference, and voltage distortion. It converts PWM switching waveforms into smooth sine-wave signals to extend motor and cable service life.

| Additional Features

| Converts PWM inverter output to sine wave

| Reduces motor eddy-current losses & noise

| Mitigates dV/dt and voltage distortion

| Enables significantly longer motor cable runs
| Reduces radiation from unshielded cables

SPECIFICATIONS

\| Rated Voltage	3Phases/220 VAC – 690 VAC
\| Rated Power	93 KW
\| Rated Current	250A
\| Rated Frequency	50/60 Hz
\| Switching Frequency	2 – 8 kHz
\| Insulation Resistance	≥ 100 MΩ at 1000 VDC
\| Protection Class	IP00 – IP22
\| Dimensions(HxWxL)	570mm x 340m x 460mm
