Longi BESS C&I H24 Liquid Cooling 0ms

Manufacturer: Longi

SKU: LC-LNG-H24-0MS

Call for pricing

FEATURES

The LONGi H24 is a next-generation Microgrid Battery Energy Storage System (BESS) featuring innovative Source-Load Decoupling (SLD) Architecture. Designed for commercial, industrial, and off-grid applications, it delivers uninterrupted power, utility grid boost capability, high renewable energy utilization, and ultra-high operational reliability.

| Additional Features

| Uninterrupted Power Supply: Keep running through any grid outage.
| Off grid Power Supply: Reliable power beyond the grid, at lower cost.
| Utility Grid Boost: To run beyond grid capacity limits.
| Renewable Energy Optimization: Maximize renewable energy utilization.
| Generator Fuel Saving: Cut oil consumption and operating costs.
| Mobile Power Station: Power anywhere, Mobile, Reusable, Reliable.

SPECIFICATIONS

\| Model	H24
\| Battery Type	LiFePO4
\| Rated Energy	261 kWh
\| Max. PV Array Power @STC	250 kWp
\| Max. DC Voltage	1000 V
\| Rated DC Voltage	600 V
\| Max. DC Input Current	10*42 A
\| MPPT Number / Max. Strings per MPPT	10/20
\| Max. Charging / Discharging Current	157 A
\| Rated AC Power [On-grid]	125 kW
\| Max. Apparent Power [On-grid]	125 kVA
\| Max. Current [AC Input On-grid]	180.4 A
\| Max. Power [AC Output Back-up]	125 kVA
\| Rated AC Voltage	380/400 V (3+N+PE)
\| Frequency Range	50/60 Hz
\| On-off-grid Switch Time	0 ms
\| Cooling	Liquid cooling
