Jinko SUNGIGA Liquid Cooling ESS Solution

SKU: SUNGIGA-JNK-LC-ESS

Call for pricing

Jinko 261 Liquid-Cooled Integrated Cabinet integrates battery modules, BMS, PCS and fire protection equipment to offer a 1000V energy storage system solution for users. This system has a battery capacity of 261 kWh and can deliver up to 125/135 kW of power. The product is characterized by flexible deployment, safety and reliability, intelligent liquid cooling, and smart software integration.

| Additional Features

| Highly Integrated: All-in-one design, integrating PCS for easy transportation and flexible O&M.| Intelligent monitoring ensures battery system safety with integrated heating system for enhanced performance and reliability.
| Smart Liquid Cooling: Non-uniform liquid cooling pipeline design effectively reduces temperature differences between battery cells.
| Smart Software: Supports remote upgrades and cloud-based monitoring platform with multi-device access.
| Flexible Multi-Unit Expansion: Modular design supporting up to 12 units in parallel.

SPECIFICATIONS

\| Model Number	JKS-261KLAA-125PLAB
\| Nominal Energy	261 kWh
\| Battery Input	LFP 3.2V / 314Ah
\| Configuration of system	1P260S
\| Number of Packs	5 pcs
\| Rated DC Voltage	832V
\| DC Voltage Range	702V ~ 936V
\| Rated AC Power	125 / 135 kW
\| Rated AC Voltage	400 Vac
\| AC Connection	3P + N
\| Rated frequency	50/60 Hz
\| On/off Grid Connection	12 units in series
\| Communication	RS485 / CAN / Ethernet
\| Cooling	Liquid Cooling
\| Protection Degree	IP55
\| Dimensions (W×D×H)	1100 × 1400 × 2400 mm
