| Overview |
The Deye 100 kW–2.5 MW Commercial & Industrial Energy Storage System (C&I ESS) is a high-performance, modular energy storage solution designed to deliver robust, scalable power management for diverse C&I applications
Built around a modular architecture including a 100 kW or 125 kW PCS (Power Conversion System) module, a 200 kW MPPT (Maximum Power Point Tracking) module, a 500 kW Static Transfer Switch (STS) module, and a 215 kWh BOS‑B lithium-ion battery bank, this system empowers businesses with flexible, reliable energy operations. |
| Key Features |
| Fast & Reliable Switching: -Seamless Switching : STS module can switch between on-grid, off-grid,and diesel modes in <30ms.
-Independent High-Power Paths : Diesel, load, and grid connections support 500kW. |
| Advanced Energy Storage: -Extended Backup : Up to 32 hours of backup with 16 racks per PCS.
-Smart Balancing: Independent BMS ensures optimal charge distribution and extends battery life. |
| Intelligent Control: -Integrated EMS : Supports zero-export and time-of-use charging/discharging.
-Easy Management: Color touchscreen for local or remote cloud adjustments. |
| Efficient PV Integration: - Wide MPPT Range : 1000V PV system with 180-850V MPPT range.
-High PV Input : Maximum 200kWp PV module connection with 8 MPPT channels, 40A per MPPT. |
| Rugged & Reliable: -IP65 Protection : PCS and MPPT modules feature IP65-rated protection.
-Peak Power Support : PCS supports and peak power up to 170%.
-LFP battery: BOS-B's robust design enhances the system's reliability. |
| High Performance & Scalability: - Powerful Capacity : PCS offers 100kW/125kW, expandable up to 2.5MW.
-Large Energy Storage: BOS-B battery delivers 215kWh per cluster, supporting up to 16 packs per PCS.
-High Efficiency: PCS reaches 98.5% efficiency, MPPT exceeds 99% |
