| The Deye SE-F16 Max is a high-performance Lithium Iron Phosphate (LiFePO4) energy storage module designed for residential and small commercial applications. Featuring an integrated smart BMS with active protection, high efficiency, and IP65/NEMA 3R enclosure protection, it provides high safety, reliability, and energy density. The battery has a nominal and usable energy capacity of 16 kWh at 51.2 V nominal voltage. The SE-F16 Max supports up to 0.5C charging and 0.7C discharging, with a maximum output power of 11.8 kW. Its modular design supports up to 32 units in parallel operation, while up to 64 units can be operated in parallel with CAN-Bridge. The battery supports wall-mounted and floor-mounted installation and provides CAN 2.0, RS485, and Bluetooth communication for monitoring. |
| Safer and More Reliable |
| Lithium Iron Phosphate (LiFePO4) chemistry with an integrated smart BMS, active protection, and active fuse for comprehensive real-time monitoring against over-voltage, under-voltage, over-current, short circuits, and temperature anomalies. |
| Ultra-High Efficiency & Power Density |
| Supports up to 0.5C charging and 0.7C discharging with up to 16 kW maximum output power. Features GaN MOSFET technology offering up to 50% loss reduction, enhanced high-temperature resistance, and an integrated PACK design to minimize line losses. |
| Flexible & Scalable Expansion |
| Modular flat design allows easy expansion up to 32 units in parallel operation (up to 512 kWh capacity, expandable up to 64 units with CAN-Bridge). Ideal for increasing self-consumption in homes and commercial setups. |
| Comfortable & Intelligent Control |
| Features automatic module interconnection (no DIP switches), local Bluetooth APP monitoring (fast pairing, portable control, no internet required), and remote monitoring/upgrades via Deye Cloud and Deye Inverter. |
| Versatile Installation |
| Space-saving design suitable for wall-mounted, floor-mounted, or stack-mounted setups. Equipped with built-in circuit breaker, side and top concealed power/communication outlets, start button, antenna, and LCD display (SOC, status, fault codes). |
| All-Weather Durability |
| Robust IP65 / NEMA 3R enclosure class with smart thermal management and natural cooling, operating reliably across wide temperature ranges (-20°C to 55°C / -4°F to 131°F; optional heater available). |
