Deye C&I MS-DC480-2 Liquid Cooling ESS

Manufacturer: Deye

SKU: LC-DEYE-MS-DC480-2

Call for pricing

The MS-DC480-2 is a high-capacity 480 kW DC charge power cabinet designed as a core component of Commercial and Industrial (C&I) PV-BESS-EV integrated charging solutions. Built to deliver flexible and scalable charging power, it features a wide DC input voltage range of 200 Vdc to 850 Vdc and provides up to eight DC output branches, each supporting a maximum output current of 250 A across a 150 Vdc to 1000 Vdc output voltage range. With a peak full-load efficiency of ≥97.5%, forced-air cooling, and an IP54-rated enclosure, the MS-DC480-2 delivers reliable, efficient, and high-performance power conversion for large-scale EV charging infrastructure.

| Additional Features

| High Power Capacity: Delivers up to 480 kW rated DC charging power with a 200–850 Vdc input voltage range.
| Multi-Branch Output: Supports 8 DC output branches with up to 250A maximum output current each.
| High Operating Efficiency: Achieves ≥97.5% efficiency at peak full-load operation, reducing energy losses.
| Wide Voltage Range: Supports 200–850 Vdc DC input and 150–1000 Vdc DC output, ensuring compatibility with high-power charging systems.
| Forced Air Cooling: Efficient forced-air cooling design provides reliable thermal management during continuous high-power operation.
| Outdoor Durability: IP54-rated enclosure with an operating temperature range of -30°C to +55°C (derating above 50°C) for reliable outdoor installation.

SPECIFICATIONS

\| Model Number	MS-DC480-2
\| DC rated input power	480 kW @ 400 Vdc ≤ Vin ≤ 850 Vdc
\| DC input voltage range	200 Vdc ~ 850 Vdc
\| DC input current range	≤ 667A
\| Dc output voltage range	150 Vdc ~ 1000 Vdc
\| Dc output current range	8 branches, max 250 A each
\| Operating Temperature Range ( ℃ )	-30℃ to +50℃（derating above 50℃
\| Cooling	Forced air cooling
\| IP Rating of Enclosure	IP54
\| Dimensions (W × H × D)	1250 mm× 2450 mm (without eyebolt)× 1000 mm
\| Approximate Weight	1200 Kg
