| Overview |
The SUN-MPPT-L01-EU-AM8 is a high-efficiency MPPT module tailored for Deye's commercial and industrial solar storage systems. Featuring 8 independent MPPT channels and a total PV input capacity of up to 200 kW, it maximizes solar energy harvest under varying conditions.
With advanced protection, precision tracking, and a rugged IP65 design, it ensures reliable and optimized PV performance in any setup. |
| Key Features |
| | High PV Capacity:Supports up to 200 kW of solar PV input with 8 independent MPPT channels, each handling up to 40 A. |
| | Wide MPPT Range:Provides a broad tracking range of 180 V to 850 V, ensuring compatibility with various PV array configurations. |
| | High Efficiency:Delivers peak conversion efficiency above 99% with MPPT accuracy over 99.9%, ensuring minimal energy loss. |
| | Multiple Input Channels: Each MPPT channel includes 2 inputs (16 in total), enabling flexible PV string design and simplified layout. |
| | Built-in Protections: Includes surge protection, DC reverse polarity protection, and insulation resistance monitoring. |
| | Rugged Construction: IP65-rated enclosure protects against dust and water ingress, ideal for indoor and sheltered outdoor use. |
| | Ease of Installation: Compact design allows for quick and straightforward integration into PV and battery systems. |
